Plan APO 500X with the Big Field
放大倍數 Magnification | 規格型號 Model | 數值孔徑 NA | 工作距離 WD(mm) | 焦距 f’ (mm) | 分辨率 R (μm) | 焦深 DF (μm) | 物方視場 on object (mm) | 像方視場 on image (mm) | 螺紋尺寸 Screw |
500x | MPlanApo(95)-500X | 0.75 | 1.96 | 0.40 | 0.44 | 0.59 | 0.10 | 50 | M26 |
Infinity optical system Plan APO objective, with the extra big field (extra 3 inch), suitable to big CCD (CMOS), very small aberration and distortion , it is a very good objective.
